Six things shape a commercial camera system: (1) what each view has to prove, (2) how long you keep footage, (3) whether your network can carry it, (4) how the site is lit, (5) what Kansas law says about audio, and (6) whether you hold federal work. Settle those six and the quote gets real.
Want your camera coverage settled on site rather than over the phone? We will come and walk the building with you.
What has to be settled before anyone can quote a camera system?
Most camera quotes arrive too early. Somebody counts the doors, adds a few for the parking lot, and hands you a number. Then the system goes in. Six months later the footage cannot answer the one question you ask it.
So the useful work happens before hardware. These six calls shape everything after them, and they belong to you rather than to your contractor. Once they are settled, picking cameras is the easy part, and our commercial security camera installation page covers that side.
- What each view has to prove. Spotting that somebody was there is a different job from naming who it was.
- How long footage has to last. That drives storage, and storage is a real line item.
- Whether the network can carry it. Cameras draw power and data from gear you already own.
- How the site is lit after dark. Light decides night quality more than the camera does.
- What the law says about audio. Video and sound are not treated the same way in Kansas.
- Whether you hold or supply federal work. In Wichita that comes up more than people expect.
How much camera detail do you need, and where?
People skip this one, and it is the one they regret. There is a real gap between three jobs a camera can do. Spotting movement. Knowing a face you already know. Naming a stranger well enough to be useful later. Each step up needs more pixels on the target.
In plain terms, a wide view of a warehouse floor and a tight view at the door do different jobs. One camera rarely does both. Detail also drops off with distance. So at every mount point, ask what this view has to achieve, not how much floor it can cover.
Choke points are where the answer lands. Doors, docks, registers, server rooms and gates earn the tight views. Open floor and yard space often just needs to show movement and which way it went. Sorting your site into those two groups is the best hour you can spend before you shop.
How long do you need to keep security footage?
Ask a facility manager and the first answer is usually 30 days. Then ask how fast problems actually surface, and the number moves. Stock loss found at inventory, a slip-and-fall claim, or a fight with a vendor can all land long after the event.
So decide this on purpose. Several things pull on it at once.
- Your insurer or a franchise deal may set a floor. Check before you specify, not after.
- Sharper images and faster frame rates eat storage, so detail and retention trade against each other.
- Recording only on motion stretches storage. But it can also miss the quiet minutes before an event.
- Multi-site firms need footage to last long enough for someone at another site to look at it.
Not sure how long your operation really needs to keep footage? That talk is part of the walkthrough, and the walkthrough is free.
Can your network carry the cameras?
Most business cameras now take power and data down one cable. That keeps the install tidy. However, it moves the limit onto your network gear. A switch has a fixed power budget, and every camera draws against it.
Three things are worth checking first. Whether your switch has spare power and spare ports. Whether the cable runs stay inside standard distance limits. And whether the recorder sits on clean, backed-up power. A recorder that dies mid-event is the failure nobody plans for.
If the cable is not already there, this becomes a wiring job as much as a camera job. Graf handles structured cabling and data wiring as its own service, so the two get scoped together rather than passed between trades. Guarding the recorder is also why commercial surge protection comes up in the same talk.
Why does site lighting decide your night camera footage?
Cameras get judged on how they see at night. Lighting usually deserves the credit or the blame. A camera aimed at a bright door from a dark lot fights that contrast every time someone walks through. Meanwhile a well-lit approach makes a plain camera look great.
That is why camera placement and commercial exterior and security lighting belong in one walkthrough. Moving a light is often cheaper than upgrading a camera. It also makes the lot better for staff and customers. Since the two systems feed each other, pricing them apart usually costs more.
What does Kansas law say about camera audio?
Video and sound are treated differently here. The Kansas breach of privacy statute, K.S.A. 21-6101, turns on whether a spot counts as a private place. The law defines that as somewhere a person can reasonably expect to be safe from uninvited surveillance. Recording sound in one of those, without consent from the people entitled to privacy there, is a misdemeanor.
Audio is where firms get caught. Many cameras ship with the mic switched on. Owning the building does not make you a party to a talk between two of your staff, so your consent is not the consent the law asks for. Restrooms and changing areas are off limits either way. This is a legal question rather than a wiring one, so check it with your own counsel before the install, not after.
Does federal contract work limit your camera options?
This one matters more here than in most cities. So many Wichita firms sit somewhere in the aerospace supply chain. Federal rules bar agencies from contracting with a firm that uses certain video surveillance gear, and the rule names specific makers. The clause is FAR 52.204-25.
Two things make this easy to get wrong. The rule reaches gear anywhere in your systems, not just gear pointed at the federal job. It also follows the equipment rather than the label on the box, so hardware sold under another name can still fall inside it. So if you hold or supply federal work, raise it at the walkthrough. It narrows the equipment list before anything else does. The Cybersecurity and Infrastructure Security Agency publishes wider guidance on site security.
What determines the size of your camera quote?
There is no price list for this work, because there is no standard job. Two buildings of the same size can differ a lot. The building decides that, not the contractor.
- How many views need the tight, name-a-stranger detail rather than general cover. This is the biggest swing factor.
- Whether usable cable already exists, and whether the routes are open or buried in finished ceilings.
- How far the recorder sits from the furthest camera, and what the path between them looks like.
- Whether the switch and power you own can carry it, or whether that gear comes along too.
- Outdoor mounting: pole work, conduit, trenching and exposure all change the labor.
- Retention, which sets storage, and storage is real hardware rather than a setting.
- Whether the work happens in an occupied building, which usually means phased or after-hours scheduling.
That is also why a number quoted before anyone has seen the building is worth very little. It prices an average building. Nobody runs one of those.
Every building is different, so every estimate we write is built around the one in front of us. Ours are free, and they start with a site walk.
What happens when you ask for a camera estimate?
Someone walks the building with you first. They look at the doors and the sight lines, check what cable and network gear is already there, and ask what each area has to achieve. Then we write it up and send it within a few days, built around your building rather than a template.
Bring anything that ties our hands. An insurance rule, a franchise standard, a federal contract, or the incident that started all this. Those shape the design more than any preference does.
Frequently asked questions
How many cameras do I actually need?
Fewer than most quotes suggest, if the placement is right. Count the spots where you would need to name a stranger, then cover the routes between them. A few well-placed cameras usually beat a lot of general views, and they cost less to store.
Can I add to the system we already have?
Often yes. It depends on whether your recorder has room left, whether the cable can be reused, and whether the old gear can talk to anything new. Bring the details of what is already in to the walkthrough. That answer changes the scope a lot.
Do I need cameras and lighting from the same contractor?
You do not have to, but the two feed each other. Light decides night image quality, and camera placement often changes where the light should go. Scoping them together tends to beat treating them as two projects with two separate site visits.
Will the install shut down my operation?
It depends on the building and where the cable has to run. Occupied spaces usually get phased or after-hours work, so the disruption stays contained. Raise your operating limits early, because they change the sequence we work in rather than the price we quote.
Who owns and watches my footage?
You do. Graf wires and installs the system rather than monitoring it. So access, how long you keep footage, and who can view it remotely are all yours to set. Decide those before the install, because they change how the system gets set up.
Who installs commercial camera systems in Wichita?
Graf Electric has been doing electrical work in Wichita since 1968. We serve business and home customers within about 15 miles of the city, and we will look at work outside that on a project by project basis. Every technician holds a Master or Journeyman Electrician license, and the crew averages more than 25 years on the job. Customers currently rate us 4.8 out of 5 across more than 100 Google reviews. You can read more about the company or see what customers say. The National Fire Protection Association sets the code standard this work is measured against, and the City of Wichita handles local permits and inspection.
If you want a camera system specified properly, get in touch and we will come and walk the building. You can also see the hardware side on our commercial security camera installation page, or the wider range our commercial electricians handle, including new construction and buildouts. We work throughout Wichita and the surrounding communities.
